Description

Feature : Ventless Hood

• Cooking Appliances Only electrically heated appliances are acceptable for installation.
• Fire Protection Completely self contained ANSUL R-102 system includes ANSUL tank, nitrogen cartridge, ANSUL sopanifier, piping, heat sensors, ANSUL drops, nozzles, and movable manual pull station
• Completely self-contained, 3-stage filtration system
• Completely self-contained fire protections system – now accessible from the front
• Very quiet with only 68 dBA average
• Interlock system will disable cooking appliances if filters are missing, clogged or in the event of a fire
• Airflow sensors continually monitor airflow for optimizing performance and grease removal
• Illuminated early-warning system to monitor filter replacement
• Completely self-contained filtration process reduces emissions below that allowed in NFPA 96 and ANSI UL710B using the EPA 202 test method
• Two LED lights producing 990 lumens for improved visibility light color temperature (cool white)
• Stainless steel construction for strength, durability and ease of cleaning
• Fits through a 36” wide door opening
• 6” to 8” adjustable legs (adjustable by 2” for leveling)
• Universal systems are movable making them ideal for leased properties
• Available in 208/240V, 1Ø
• Exhaust and Air Flow Exhaust air is vertical discharge. Typical airflow is 800 CFM. A minimum of 400 cubic feet of fresh air per minute is recommended both in and out of the cooking area to ensure the dilution of cooking aromas.
